Lightweight aggregate concrete

High Efficiency Cooling and Refrigeration Coating

Lightweight concrete has long been used for suspended floors in order to reduce the weight on the structure and to increase the fire rating. And since a lightweight floor is typically thinner (5.25 inches versus 6.5 inches with normal weight for the equivalent fire rating), a lightweight floor will be 40% to 45% lighter than a normal-weight floor. So while lightweight concrete does cost a little more, with the reduction in weight, the building frame costs less. But lightweight concrete has other advantages when designed to take advantage of internal curing.

Strength grade	Density gradekg/m3	28 days shrinkage value mm/m	Ultimate compressive strain	Permeability grade	Antifreeze level
LC30	≥1200	≤0.36	0.0019	P6	P100
LC40	≥1400	≤0.36	0.0020	P6	P100
LC50	≥1700	≤0.36	0.0023	P8	P150
LC60	≥1800	≤0.36	0.0024	P8	P200

The core technology

Light weight (low density admixture, density class≤1900kg/m3）
LC60High strength (high strength light aggregate, reinforced mineral admixture)
Inhibit buoyancy (uniform distribution of light aggregate

Application scenarios

Lightweight aggregate concrete

Roof insulation

Highway construction and paving

Fabricated box culvert

Test Item	GJJ/T 135-2009	Typical value of this product
Permeable coefficient	≥0.5mm/s	5.1mm/s
Continuous porosity	≥10%	10%~20%
The compressive strength(28d)	C20≥20.0MPa C30≥30.0MPa	24.4MPa 33.5MPa
Flexural strength(28d)	C20≥2.5MPa C30≥3.5MPa	2.8MPa 3.6MPa
Surface decoration	-	With a variety of colors, textures, patterns of decorative effects

Through bionic design, "lotus leaf effect" can be achieved on the surface of the coating perfectly, and the dust on the surface can be taken away by gravity under the erosion of rain to achieve self-cleaning effect. It is suitable for the coating of ordinary buildings, external walls of super high-rise buildings or prefabricated components.

Item				Result
Self-cleaning performance	Contact Angle（°）			≥150°（Super hydrophobic self cleaning paint）
				≥100°（Hydrophobic self cleaning paint）
Basic performance	State in the container			Normal
	Low temperature stability			Never degenerating
	The drying time（Surface dry）/h		Smooth coating effect	≤2
			The texture effect	≤4
	Composite coating	Coating appearance		Normal
		Adhesive force	Smooth coating effect	≤1级
			The texture effect	No fall off
		Resistance to water（96h）		Normal
		Resistance to alkali（48h）		Normal
		Resistance to damp, cold and heat cycle（5times）		Normal
		Resistance to artificial climate aging（600h)	Smooth coating effect	No bubble, no peeling, no crack, powder≤2级
			The texture effect	No bubble, no peeling, no crack, no obvious powder

Hydrophobic self-cleaning: contact Angle is greater than 100°, with obvious "lotus leaf effect", surface dust can roll down with rain, saving cleaning costs
Pefect weather resistance: Well acid and alkali resistance, aging resistance, widely applicable to a variety of climate conditions of the constructions
Environment friendly: water-based paint, healthy and environmentally friendly, no secondary pollution
Convenient to use: suitable for a variety of coating construction technology, can roll, spray, brush

A new type of high-performance concrete with the addition of graphene, carbon nanotubes and other nanomaterials in ordinary concrete to meet specific functional requirements, with electric heating, pressure sensitivity, electromagnetic shielding and other functions.

The core technology

Results of snow melting and ice melting test of rut plate specimen
Product features
Electromagnetic shielding effect

Shielding radio interference, the role of defense electromagnetic wave
Environmental heating, building heating and deicing of roads and airports
